Siemens SIMATIC S7-1200 /S7-1500

Features:

✅ Compact & Modular Design
✅ Integrated PROFINET Interface
✅ High-Speed Counters & Pulse Outputs
✅ PID Control Function Blocks
✅ Scalable I/O Expansion
✅ Industrial Security Integrated
✅ Integrated Display

Siemens SIMATIC PLCs are designed for reliable, flexible, and efficient automation across all industrial environments. The S7-1200 series targets compact automation tasks with integrated communication and technology functions, while the S7-1500 series delivers high-end performance, advanced safety, and scalability for complex applications.

Brand	Siemens

Description
Technical Data
Application
Downloads
Supply & Shipping Deatils

Description

Siemens SIMATIC S7-1200 and S7-1500 PLCs are advanced automation controllers built for flexibility, scalability, and high-performance control in a variety of industrial applications. The compact and modular S7-1200 is ideal for basic automation tasks, while the S7-1500 is designed for complex and demanding applications requiring top-tier processing speed, safety, and communication.

SIMATIC S7-1200: Compact, cost-effective, and perfect for small to mid-size applications.
SIMATIC S7-1500: High-performance controller with integrated diagnostics, motion control, and security features.

Technical Data

Siemens SIMATIC S7-1200 / S7-1500 PLCs

🔹 SIMATIC S7-1200 PLC ▾

CPU Models CPU 1211C, 1212C, 1214C, 1215C, 1217C

Program Memory 50 KB – 125 KB

Data Memory 1 MB – 2 MB

Instruction Execution Time ~0.08 µs per bit operation

Number of I/O Up to 284 digital/analog I/O (with expansion)

Communication Ports 1x PROFINET, Modbus TCP, TCP/IP

Integrated Functions PID Control, High-Speed Counters, PWM, PTO

Web Server Built-in for diagnostics and monitoring

Communication Protocols PROFINET, MODBUS, TCP/IP, S7 communication

Expansion Modules Digital I/O, Analog I/O, RTD/TC, Communication Modules

Power Supply 24V DC

Mounting Type DIN Rail

Protection Class IP20

🔹 SIMATIC S7-1500 PLC ▾

CPU Models CPU 1511, 1513, 1515, 1516, 1517, 1518

Program Memory 250 KB – 10 MB

Data Memory 1 MB – 50 MB

Instruction Execution Time ~1 ns per bit operation

I/O Capacity Up to 32,768 I/O points (local + distributed)

Communication Ports 2x PROFINET, PROFIBUS, Industrial Ethernet, OPC UA

Integrated Display 2.4” color diagnostics screen

Redundancy Available in S7-1500R/H series

Integrated Features Motion Control, Safety Integrated (F-CPU), Web Server

Security Functions Access protection, copy protection, encrypted communication

Communication Protocols PROFINET, PROFIBUS, OPC UA, Modbus, TCP/IP

Mounting Type DIN Rail

Protection Class IP20

Application

Factory Automation – Process control, machine automation, production lines.
Packaging Machines – Motion control, synchronization, and precision timing.
Water/Wastewater Management – Pump control, level sensing, and remote telemetry.
HVAC and Building Automation – Integrated with sensors and energy systems.
Food & Beverage Industry – Hygiene-compliant automation with rapid changeover.
Oil & Gas / Energy – Reliable operation in mission-critical control environments.
